The printer supports Serial communication. It can have also a magnetic stripe reader for operator identifications. CMP-10 also has a high capacity battery pack which allows users to print for many days without recharging the battery.

Printing Mechanism: Direct line thermal printer

Printing Width: 48 mm (384 dots)

Printing Resolution: 203 x 203 dpi (8 x 8 dpmm)

Printing Speed Max: 50 mm per second

Printable Font Sizes: Font A - 32 characters per line

Font B - 42 characters per line

Printable Barcode Types 1D: EAN-13, EAN-8, UPC-A, UPC-E, Code 39, Code 128, Interleaved 2 of 5, Codabar

Paper Type: Thermal paper rolls

Paper Width: 57 mm

Paper Thickness: 60 to 65 μm

Roll Max Diameter: 50 mm

Paper Loading: Easy paper loading

Emulation ESC/POS

Connectivity RS-232C port

OS Compatibility Palm, BlackBerry, Windows, Android, iOS devices

LED Indication Battery low

Paper End

Cover open

Overheating

Keyboard and Buttons On/Off button

Feed button

Power Supply: AC 100 to 240 V, 50 to 60 Hz, DC 9 V, 1 A

Battery: Rechargeable Li-Ion battery 7.4 V, 2000 mAh

3 hours charging time

40 000 lines with one charge

Reliability 50 million pulses, 50 km (Thermal head)

15 million lines (Mechanism MCBF)

Certificates CE

Dimensions (W x D x H): 116 x 104 x 63 mm

Weight: 370 g

Operational temperature range: 5 to 40 °C, 35 to 85 % RH

Storage temperature range: -20 to 60 °C, 10 to 90 % RH

Drop Tested: 1.2 m, 3 times, all sides on concrete
