Integrated Mechanism Design. Extra Large Paper Roll Windows, Auto Label Type Detection.

Printing Method Direct Thermal / Thermal Transfer

Resolution:203 dpi（8 dots/mm）

Printing Speed: 2 ips ~ 5 ips

Printing Width: 25.4 mm ~ 108 mm

Programming Language: TSPL, ZPL

Barcode: BarcodeCode 39, Code 93, Code 128UCC, Code 128, Codabar, Interleave 2 of 5, EAN8, EAN13, UCC/EAN128, UPC-A, UPC-E, MSI, PLESSEY, POSTNET,RSS-Stacked, GS1 DataBar, Code 11

2D CodeQR Code, PDF417, DataMatrix, Aztec

Printing Length 15 mm ~ 1200 mm

Media TypeRoll-fed, Fan-fed, Die-cut, Continuous Label, Tag stock

Diameter (Media Roll)127 mm

Thickness 80 μm ~ 180 μm

Diameter(Core)0.5"(12.7 mm), 1"(25.4 mm), 1.5"(38.1 mm)

Ribbon TypeWax, Resin/Wax, Resin Length300 m

Sensors: Gap SensorTransmissive (Fixed)

Black Mark SensorReflective (Adjustable, Half-Range)

OtherHead-Up Sensor, Ribbon End Sensor, Paper Out Sensor

InterfaceStandardUSB Type-B, Serial Port, Ethernet

OptionalBluetooth, Wi-Fi

HICButtonFeed

Indicator LightReady Sig.(Green), Status Sig.(Red)

Power AdapterInputAC 100 ~ 240V, 50/60 Hz

OutputDC 24V, 2.5A

Input VoltageAC 100V ~ 240V, 50/60Hz

Reliability:TPH50 km

Memory: RAM32 MB ROM16 MB

Softwares: DriverWindows Vista/7/8/10 Windows Server 2008/Server 2012/Server 2016

Options and Accessories: External 8-inch Label Roll Holder

Cutter Module (H4GC, Black)

Peeler Module (H4P, Black)

Physical Characteristics285(L)×226(W)×171(H) mm

Empty Weight2.26 kg

Agency ApprovalsCCC, FCC, CE
