The new DP05 portable cash register model is approved in accordance with the provisions of Art. (2) of GEO 28/1999, Art.17 lit.f) of the Implementing Rules.
There is no dedicated port for the scanner (order cash register with built-in code scanner).
Maximum number of items that can be stored in the database - Up to 100,000
Item article length (PLU) - Up to 72 characters
Bar Code Types Attached to Items - EAN-13, EAN-8, UPC, Barcode Label Label
Types of fees - VAT rates: 5 programmable allowances, 1 share x VAT excluded; other taxes
Articles Groups - Up to 99
Departments - Up to 99
Number of operators - Up to 30
Payment Types - Cash (default); Fixed: cash back, bank card, voucher, credit, modern payment methods, gift vouchers, lunch vouchers; Programmable: others
AMEF modes of operation ▪ 1 / Sale (Registration); ▪ 2 / Reports X; ▪ 3 / Fiscal Reports; ▪ 4 / Programming; ▪ 5 / Rap.Info AMEF; ▪ 6 / PC connection; ▪ 7 / Service; ▪ 8 / Tests; ▪ 9 / Electronic Journal
Communication with RS: ▪ for programming, reading and issuing reports in the database of articles;
▪ to configure the AMEF parameters;
▪ for the issue of tax vouchers, closure reports and the issuance of non-tax documents.
Electronic Log - Yes (Storage on microSD card from 8GB to 32GB)
Fiscal memory - Non-volatile, 2500 daily tax reports
Cryptographic Mode - EAL 5+
Electronic Signature - X.509.V3, RSA 2048 bits
Characters printed per line - 42
Bluetooth Module - Optional
Thermal Printer - MLT-289 XS
Battery - Li-Ion 7,4V 2000mA / h
Print Speed - 12 lines / second
Graphic Print (Graphic Logo, Barcode) - Supported Size 384 x 96 dots (max 384 x 336 dots); Barcode types: EAN8, EAN13, Code128, interleaved 2of5, QR code
Consumables - thermal paper ▪ Width 57 mm / ▪ Thickness from 60 to 72 μm / ▪ Roller diameter up to 50 mm
Operator Screen ▪ LCD graphic, 2 x 16 lines
Customer Display ▪ LCD graphic, 1 line x 16 characters (optional)
Keyboard - 29 keys
Power supply - Power supply - 9Vcc / 1A, input: 100-240V 50-60Hz
Internal clock battery / calendar (new battery) - Provides operation for 90 days after disconnecting from the power source
Operating Temperature and Humidity - From -10 C to + 45 C / Relative Humidity without Condensing 40-80%
Dimensions (width x length x height) mm - 88/194/66
Weight, kg - 0.525 kg (with paper roll included)
Interface for additional devices ▪ 1 x mini USB - can be configured to work on PC connection, or can be used to download files is mf.
▪ Built-in bar code reader - optional
▪ Built-in GSM / GPRS modem (Quecattel M66, SAR body 1.683W, GSM 900/1800 MHz)
Mandatory "Keep the bill" and "Consumer protection" bills are delivered free of charge if requested.
Made in Bulgaria.
