Thermal transfer technology. Big capacity of ribbon. Adjustable paper width. Low printing noise

Printing Method:Direct Thermal / Thermal Transfer

Resolution:203 dpi（8 dots/mm）

Printing Speed:2 ips ~ 5 ips

Printing Width:25.4 mm ~ 108 mm

Programming Language:TSPL, ZPL

Barcode:Linear BarcodesCode 39, Code 93, Code 128UCC, Code 128, Codabar, Interleave 2 of 5, EAN8, EAN13, UCC/EAN128, UPC-A, UPC-E, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11

2D BarcodesQR Code, PDF417, DataMatrix, Aztec

Printing Length:15 mm ~ 1200 mm

Media:TypeRoll-fed or Fan-fed, Die cut or Continuous direct thermal labels with or without black mark, Tag stock

Diameter(Media Roll)127 mm

Thickness76.2 μm ~ 177.8 μm

Diameter(Core)0.5"(12.7 mm), 1"(25.4 mm), 1.5"(38.1 mm)

Ribbon:TypeWax, Resin/Wax, Resin; Length100 m

Sensors:Gap SensorTransmissive (Fixed)

Black Mark SensorReflective (Adjustable, Half-Range)

OtherHead-Up Sensor, Ribbon End Sensor, Paper Out Sensor

Interface:StandardUSB Type-B, Serial Port, Ethernet

OptionBluetooth, Wi-Fi

HIC:ButtonFeed

Indicator LightLED (Three colours)

Power Adapter:InputAC 100 ~ 240V, 50/60 Hz, OutputDC 24V, 2.5A

Reliability:TPH50 km

Memory:RAM32 MB; ROM16 MB

Softwares:DriverWindows Vista/7/8/10

Windows Server 2008/Server 2012/Server 2016

Options and AccessoriesExternal 8-inch Label Roll Holder

Cutter Module (G4GC, Black)

Peeler Module (G4P, Black)

Physical Characteristics240(L)×225(W)×171(H) mm

Empty Weight2.26 kg

Agency ApprovalsCCC, FCC, CE
